Rimfire Blank

Name: Rimfire Blank
SKU: 220113
Availability: InStock

$375.00

Craft your own match-grade rimfire blank. Custom built to your order. Select your length and contour.

Length Notice *

I acknowledge that an inch has been removed from the breech, and the barrel I receive will be 1" longer than the finish length I selected.

Breech Diameter (.900-1.200")*

BL - Breech Length (2.75-10")*

BL - Breech Length (2.75-5")*

NL - Neck Length (4.5-8")*

ND - Neck Diameter (0.800-1.200")

MD - Muzzle Diameter (.600-1.200")

Total: $375.00

Categories: Barrel Blanks, Rimfire

Description

We designed our rimfire blanks for all shooters, regardless of experience, and for use in a wide range of applications. Each blank comes in stainless steel, .22RF, and 1-16 twist. Customize your length and select from an industry standard contour or create the profile you have always envisioned. We machine our rimfire blanks from meticulously inspected high-grade ordnance steel to exacting tolerances. Each rimfire blank is hand-lapped to precise bore and groove diameters, a pristine finish with a continuous bore taper to optimize engraving for bullet stability and accuracy, and a consistent rate of twist from breech to muzzle. The profiles are polished and free of machining marks—ready to be threaded, chambered and crowned by your gunsmith.

Whether you are building your next rifle to compete at the highest level, hunt small game, or plink targets, our rimfire blanks provide match-grade performance. Every barrel blank is made to order and shipped in approximately 8 weeks. Payment is required upon placing the order.

Tapered Contour Options:

Contour	Finish Length	Muzzle Diameter	Approximate Weight	Fluting Option
Straight	Up to 26″	Up to 1.250″	N/A	All Calibers
Bull	Up to 26″	1.000″	7.25 lbs @ 26″	All Calibers
MTU	Up to 26″	0.920″	6.75 lbs @ 26″	All Calibers
M24	Up to 26″	0.900″	6.0 lbs @ 26″	All Calibers
Heavy Varmint	Up to 26″	0.900″	6.75 lbs @ 26″	All Calibers
Light Varmint	Up to 26″	0.875″	6.5 lbs @ 26″	All Calibers
Heavy Target	Up to 26″	0.875″	6.5 lbs @ 26″	All Calibers
Standard Target	Up to 26″	0.820″	6.0 lbs @ 26″	Up to 7mm
Light Target	Up to 26″	0.750″	5.75 lbs @ 26″	Up to 7mm

Sporter Contour Options:

Contour	Finish Length	Neck Diameter	Muzzle Diameter	Approximate Weight	Available Calibers	Fluting Option
Bull Sporter	Up to 26″	0.900″	0.700″	4.0 lbs @ 26″	Up to .30 Cal	Not Available
Heavy Sporter	Up to 26″	0.870″	0.670″	3.75 lbs @ 26″	Up to .270 Cal	Not Available
Medium Sporter	Up to 26″	0.830″	0.630″	3.5 lbs @ 26″	Up to 6mm	Not Available
Standard Sporter	Up to 26″	0.800″	0.600″	3.25 lbs @ 26″	Up to .22 cal	Not Available

Palma Contour Options:

Contour	Finish Length	Neck Diameter	Muzzle Diameter	Approximate Weight	Fluting Option
Heavy Palma	Up to 26″	1.000″	.900″	6.0 lbs @ 26″	All Calibers
Standard Palma	Up to 26″	.900″	.800″	4.75 lbs @ 26″	Not Available
Light Palma	Up to 26″	.900″	.750″	4.5 @ 26″	Not Available
